Description
Specifications
Model Parameters
Model CS-CV246-B0-3B2WFRCS-CV246-B0-3B1WFR
Camera
Image Sensor 1/2.7″ Progressive Scan CMOS1/4″ Progressive Scan CMOS
Shutter Speed Self-adaptive shutter
Lens 4mm@ F2.2, Diagonal angle: 90°
PT Angle Pan: 340°, Tilt: 120°
Lens Mount M12
Day & Night IR-cut filter with auto-switching
3D DNR
Digital WDR
Compression
Video Compression
H.264 Type
Main profile
Video Bit Rate HD, Balanced and Smooth bit rate
Max. Resolution 1920×10801280×720
Image setting Brightness, contrast, saturation, etc. (configurable via EZVIZ Studio)
BLC
Support
Network
Storage Support Micro SD card (Max. 128G)
Smart Alarm
Motion detection
Wi-Fi Pairing
SmartConfig (Wi-Fi One-Key Configuration)/AP paring
Protocol EZVIZ cloud proprietary protocol
Interface Protocol EZVIZ cloud proprietary protocol
General Features
Anti-Flicker, Dual-Stream, Heartbeat Messages, Mirror Image, Password Protection, Watermark
Minimum Network Requirements
2Mbps Wi-Fi
Standard IEEE802.11b, 802.11g, 802.11n
Frequency Range 2.4 GHz ~ 2.4835 GHz
Channel Bandwidth Supports 20MHz
Security 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK
Transmission Rate 11b: 11Mbps, 11g: 54Mbps, 11n: 135Mbps
General
Operating Conditions -10°C ~ 45°C, Humidity 95% or less (non-condensing)
Power Supply DC 5V±10%
Power Consumption Max. 7WMax. 5.5W
IR Range Max. 10 meters
Product Dimensions 87.7mm x 87.7mm x 112.7mm
Packaging Dimensions 106mm x 106mm x 190mm
Weight 256g
